Additional information
| SIZE | 4.8” x 4.8” x 1” |
|---|---|
| WATTS | 9W |
| CCT | RGBWW |
| VOLTAGE | 120V |
| DIMMABLE | Yes |
| IP RATING | IP44 |
| BEAM ANGLE | 110° |
| CRI | 80 |
| PF | 0.9 |
| FINISH | White |
| MATERIALS | Aluminum, PMMA |
| LIFESPAN | 50,000 Hours |
| DESCRIPTION | LED Slim Downlights can be safe to use in damp locations that rarely have direct water contact, such as bathrooms and awnings. Extremely thin for tight locations and no housing or additional hardware is required. The junction box is included for easy installation. This product lets you change the color and color temperature using an app. LED Downlights are perfect for gas stations, hotels, and offices. |
SPECIFICATIONS
SDL – 02 – Slim Downlight RGB – Specifications
INSTRUCTIONS
SDL4 SDL6 – RGBWW Slim-Downlight – Smart Control – Installation
IES FILES
SDL6 – CCT Slim Downlight 6IN – 12W – IES
PHOTOMETRICS
SDL6 – CCT Slim Downlight 6IN – 12W – Photometrics
COMMON STOCK MODELS
| ITEM CODE | MODEL NUMBER | PRODUCT DETAILS |
| 11293 | SES-SDL4-02-RGBWW-9 | 4″ Slim Downlight, RGB+ (2700-6500K), 9W |
| 11294 | SES-SDL6-02-RGBWW-12 | 6″ Slim Downlight, RGB+ (2700-6500K), 12W |
| 40192-A | SES-SDL4-TRIM-BR | Downlight Slim Downlight 4″ Bronze Trim |
| 40192-B | SES-SDL4-TRIM-BL | Downlight Slim Downlight 4″ Black Trim |
| 40192-C | SES-SDL4-TRIM-BN | Downlight Slim Downlight 4″ Brushed Nickel Trim |
| 40193-A | SES-SDL6-TRIM-BR | Downlight Slim Downlight 6″ Bronze Trim |
| 40193-B | SES-SDL6-TRIM-BL | Downlight Slim Downlight 6″ Black Trim |
| 40193-A | SES-SDL6-TRIM-BN | Downlight Slim Downlight 6″ Brushed Nickel Trim |
SES-SDL4-02-RGBWW-9
