Description
CCT & POWER switchable commercial downlight. with two ears clips and can install without bracket. 100-277V, 70 deg Beam Angle, 1200 / 1840 / 2400 lumens, 80 CRI, >0.9PF, UL & Energy Star
Additional information
| SIZE | 7.7" L x 7.7" W x 5.9" D |
|---|---|
| WATTS | 15W /23W/30W |
| CCT | 3000K, 4000K, 5000K |
| VOLTAGE | 100-277V |
| DIMMABLE | Yes |
| IP RATING | IP20 |
| BEAM ANGLE | 70° |
| CRI | 80 |
| PF | >0.9 |
| FINISH | Silver |
| MATERIALS | Aluminum |
| LIFESPAN | 5 |
| DESCRIPTION | Extremely easy to install, this powerful recessed downlight is equipped with a quick-connect case and conduit to integrate with an existing fixture frame junction box. Set your color temperature between warm, daylight, and cool options. Not only is this light dimmable to 5%, but you can switch between three wattage settings to control your energy consumption. Get comfortable diffused light with no hot spots or dark areas. |
Additional information
| SIZE | 7.7" L x 7.7" W x 5.9" D |
|---|---|
| WATTS | 15W /23W/30W |
| CCT | 3000K, 4000K, 5000K |
| VOLTAGE | 100-277V |
| DIMMABLE | Yes |
| IP RATING | IP20 |
| BEAM ANGLE | 70° |
| CRI | 80 |
| PF | >0.9 |
| FINISH | Silver |
| MATERIALS | Aluminum |
| LIFESPAN | 5 |
| DESCRIPTION | Extremely easy to install, this powerful recessed downlight is equipped with a quick-connect case and conduit to integrate with an existing fixture frame junction box. Set your color temperature between warm, daylight, and cool options. Not only is this light dimmable to 5%, but you can switch between three wattage settings to control your energy consumption. Get comfortable diffused light with no hot spots or dark areas. |
SPECIFICATIONS
CDL6 – 6in CCT Commercial Downlight – 15-30W – Specifications
INSTRUCTIONS
CDL6 – 6 Commercial Downlight – Installation
IES FILES
CDL6 – Commercial Downlight 6IN – 27W – IES
CDL6 – CCT Commercial Downlight 6IN – 30W – IES
PHOTOMETRICS
CDL6 – Commercial Downlight 6IN – 27W – Photometrics
CDL6 – CCT Commercial Downlight 6IN – 30W – Photometrics
COMMON STOCK MODELS
| ITEM CODE | MODEL NUMBER | PRODUCT DETAILS |
| 10190 | SES-CDL6-CCT-30 |
Downlight 6″ Commercial Downlight, CCT & Watt Adjustable 3000K + 4000K + 5000K 15W / 23W / 30W
|
| 10191 | SES-CDL8-CCT-50 |
Downlight 8″ Commercial Downlight, CCT & Watt Adjustable 3000K + 4000K + 5000K 37W / 42W / 50W
|
